Aluminium Bronze Investment Castings : Grades, Heat Treatment and Applications

Aluminium bronze investment casting — also known as lost wax casting of copper-aluminium alloys — is one of the most misspecified processes in precision casting procurement. Not because the alloy is poorly understood in general, but because the name 'aluminium bronze' covers nine distinct ASTM casting grades whose properties, heat treatment requirements, and service capabilities are so different from one another that specifying the family name without the grade number and heat treatment condition is, in practical terms, not a specification at all.

This guide covers all nine grades — from C95200 to C95900 — with their equivalent US, British, and European specifications, how heat treatment affects each alloy’s microstructure, mechanical properties, and corrosion resistance, and where each grade performs best in real industrial service. It also explains which aluminium bronze grades are preferred for heavy-duty bearings, marine hardware, valve bodies, pump impellers, wear plates, aerospace components, and high-load industrial castings.

For readers looking for a deeper technical reference on copper alloy metallurgy, gating and feeding practices, heat treatment behavior, casting defects, machining considerations, alloy selection, and industrial applications, refer to the full guide: “Copper, Brass, and Bronze Investment Casting: Metallurgy, Process Control, and Industrial Applications.”

Nine Grades of Aluminium Bronze for Lost Wax Casting

Each grade in the aluminium bronze family is defined by its aluminium content and by its iron and nickel additions, which together determine where the grade sits on the strength-corrosion resistance-heat treatment spectrum. The grade selection decision is a service environment decision, not a cost decision. The material saving from specifying C95400 where C95800 is required disappears entirely when the casting fails in service and must be replaced.

C95200 — Cast Aluminium Bronze

C95200 — approximately 9% aluminium, iron addition for grain refinement, no nickel — is the entry point of the aluminium bronze family. Its value is in castability: good fluidity, predictable shrinkage, and a low tendency toward hot cracking make it the most straightforward grade to cast with consistent quality.

Yield strength in the as-cast condition is approximately 140 MPa, and corrosion resistance is adequate for general industrial service in non-aggressive environments — bearings, bushings, and wear parts in dry or mildly corrosive conditions.

What C95200 cannot do is protect itself reliably in seawater or high-chloride environments. The alloy lacks the nickel that stabilises the kappa phase and makes the protective oxide film coherent under sustained aggressive attack. Specifying C95200 for seawater service to save material cost is a decision that typically results in premature failure through dealuminification — a failure mode discussed in detail below. European equivalent: CC330G under EN 1982.



C95300 — High-Strength Aluminium Bronze

C95300 (approximately 10% Al, 0.8–1.5% Fe) is the least discussed grade in the aluminium bronze family, which is a missed opportunity — because when heat-treated to the TQ50 temper, it delivers yield strength of approximately 310 MPa at a cost point below the nickel-bearing grades. Bearing segments for the steel industry, cams, mining machine components, high-strength clamps, and electrical connectors are the primary applications.

The critical point for buyers: as-cast C95300 does not deliver these properties. A purchase order without a specified heat treatment condition will result in a casting at roughly half the grade's strength potential. European designation: CC331G (EN 1982); DIN: G-CuAl10Fe3.



C95400 — Aluminium Bronze Bearing Alloy (AB1)

C95400 (approximately 10.5% Al, 3–5% Fe) is the most widely cast aluminium bronze grade. Known in British and European specifications as the AB1 equivalent under BS 1400, it delivers reliable yield strength of approximately 205 MPa as-cast, rising with annealing, at a cost and castability point that makes it the default choice for general industrial applications.

Pump bodies, valve housings, butterfly valve discs and stems, gear blanks, bearing sleeves, and fluid-handling components across chemical processing and heavy engineering are the core C95400 market.

The mistake buyers make with C95400 is treating it as a universal aluminium bronze. It is excellent in its range — general industrial service, moderate corrosion environments, wear and strength requirements. It is not adequate for continuous seawater immersion or high-chloride environments.

Upgrading to C95500 or C95800 for seawater applications is not a luxury — it is what prevents dealuminification. European designation: CC331G (EN 1982); DIN: G-CuAl10Fe3.



C95500 and C95520 — Nickel Aluminium Bronze

The nickel addition in C95500 (approximately 11% Al, 3–5.5% Ni, 3–5% Fe) does two things simultaneously: it raises yield strength to approximately 275 MPa as-cast, and it meaningfully improves the alloy's resistance to dealuminification in moderately aggressive environments.

The nickel stabilises the kappa phase and makes the protective oxide film more coherent under sustained chloride attack. C95500 is the correct choice when C95400 is borderline on strength or when the service environment is more aggressive than general industrial conditions but does not require the full seawater specification of C95800. European designation: CC332G (EN 1982).

C95520 — designated AMS 4881 in aerospace and defence procurement — is the high-performance heat-treated variant of the C95500 family, and it occupies a different category entirely. Solution treated and tempered, it achieves yield strengths above 480 MPa — comparable to medium-carbon steel — while retaining the corrosion resistance and low magnetic permeability of the nickel aluminium bronze family.

Developed for aircraft landing gear bushings and bearings, it has extended into BOP components, high-pressure oil and gas fittings, and heavy-load defence bearings. There is one rule for C95520: specifying it without a heat treatment condition is a meaningless specification. The properties are entirely a product of the solution treatment and temper cycle. European equivalent: CC333G (EN 1982).



C95600 — Silicon Nickel Aluminium Bronze

C95600 takes a different approach to the aluminium bronze composition: rather than high aluminium with iron and nickel additions, it uses a silicon addition (approximately 6% Si, 7% Al) that improves castability and machinability while maintaining useful corrosion resistance.

The result is a grade well-suited to components that are difficult to cast or machine in the higher-strength grades — cable connectors, terminals, valve stems, gears, and worm drives in electrical and industrial applications. C95600 is not a marine or high-corrosion grade; its protective film is less robust than the nickel-bearing grades in aggressive seawater, and it should not be specified where C95500 or C95800 properties are required.



C95700 — Manganese Nickel Aluminium Bronze

C95700 (approximately 8% Al, 11–14% Mn, 1.5–3% Ni, 2–4% Fe) is the high-manganese variant of the nickel aluminium bronze family. Understanding why manganese is present requires a brief metallurgical note: in aluminium bronze, six percent manganese is metallurgically equivalent to one percent aluminium in its strengthening effect.

The high manganese content acts as a beta phase stabiliser and strengthener, producing yield strengths of approximately 310 MPa as-cast in a grade that is less sensitive to section thickness variation than the higher-aluminium grades. C95700 occupies a similar application space to C95800 for heavy-duty pump impellers, marine hardware, and valve bodies in moderately aggressive environments where maximum strength is the primary driver and the full seawater corrosion resistance of C95800 is secondary.



C95800 — Marine Nickel Aluminium Bronze (AB2)

C95800 (approximately 9% Al, 4–5.5% Ni, 3–5% Fe, 0.8–1.5% Mn) is the grade that defines what aluminium bronze can do at its best. Known as AB2 under BS 1400 and CC333G (CuAl10Ni5Fe4-C) under EN 1982, produced to MIL-B-24480 for naval applications — it is the standard material for marine hardware, seawater pump internals, offshore valve bodies, naval components, and industrial fire suppression systems, and it is essentially irreplaceable in those applications.

What makes C95800 the marine standard is not any single property but the combination: superior seawater corrosion resistance exceeding C95500, cavitation erosion resistance that protects pump impellers and propellers under high-velocity flow, biofouling resistance — the biostatic surface deters barnacle and algae attachment without coatings — and magnetic permeability below 1.05, which makes it the naval standard for sonar housings, mine countermeasure vessels, and submarine hardware. C95800 must be heat-treated for seawater service — this is discussed in detail in the section below.



C95900 — Manganese Aluminium Bronze

C95900 has the highest aluminium content of the standard casting grades — approximately 11–12% Al with 4–5.5% Fe — producing maximum hardness and wear resistance in the aluminium bronze family, with as-cast yield strengths approaching 380 MPa. The high aluminium content requires careful heat treatment to avoid retained beta phase, which reduces toughness. Applications are dominated by wear resistance requirements: forming dies, heavy wear plates, tooling components, and parts subject to abrasive wear where the alloy's extreme hardness is the primary selection driver.

Grade Comparison — US, British and European Designations

The table below cross-references all nine ASTM grades with their British (BS 1400), European (EN 1982), and common name equivalents, together with indicative as-cast yield strength and heat treatment requirement.

UNS Grade	BS 1400	EN 1982	Common Name	Al %	Ni %	Yield As-Cast	Heat Treatment
C95200	—	CC330G	Cast Aluminium Bronze	~9	—	~140 MPa	Optional — anneal for stress relief
C95300	—	CC331G	High-Strength Al Bronze	~10	—	~170 / 310 MPa (TQ50)	Recommended — TQ50 for full strength
C95400	AB1	CC331G	Al Bronze Bearing Alloy	~10.5	—	~205 MPa	Recommended — annealed standard supply
C95500	—	CC332G	Cast NAB	~11	~4	~275 MPa	Recommended — anneal or solution treat
C95520	—	CC333G	High-Perf. NAB (AMS 4881)	~11	~5	≥480 MPa (HT)	Mandatory — solution treat + temper
C95600	—	—	Silicon NAB	~7Al/6Si	—	~205 MPa	Optional
C95700	—	—	Manganese NAB	~8	~2	~310 MPa	Recommended
C95800	AB2	CC333G	Marine NAB (MIL-B-24480)	~9	~5	~250 MPa	Mandatory — seawater service
C95900	—	—	Manganese Al Bronze	~12	—	~380 MPa	Recommended — solution treat + temper

What Heat Treatment Does — and Why As-Cast Is Often the Wrong Specification

Heat treatment of aluminium bronze is where the most avoidable procurement mistakes happen. The issue is a failure mode called dealuminification: the selective leaching of aluminium from the alloy surface in aggressive seawater and acid environments, which leaves behind a porous, mechanically weak copper matrix with no structural integrity. The part looks intact from the outside. Inside, it has been hollowing out from the moment it entered service.

Dealuminification happens because the protective alumina film relies on a coherent, homogeneous microstructure to be reliable. In an as-cast aluminium bronze, the kappa phase distribution is uneven — driven by variable cooling rates through the mould.

This unevenness produces a film that is less coherent and more susceptible to sustained attack in aggressive seawater environments. Heat treatment produces the homogeneous, fine kappa phase distribution that makes the protective film reliable and eliminates dealuminification susceptibility.

For C95800 in seawater service, an as-cast supply condition is a specification error, not a cost saving. For C95520, the situation is more direct: without solution treatment and temper, the casting simply does not achieve its rated strength. No inspection process corrects a heat treatment that was not performed. The practical implication: the heat treatment condition must appear on the purchase order. Specifying the UNS grade alone leaves the foundry free to supply as-cast material.

Lost Wax Casting vs Sand Casting for Aluminium Bronze

The manufacturing route decision for an aluminium bronze component comes down to geometry first, then production volume.

Investment casting — the lost wax casting process — is the route for components where geometric complexity, thin walls, and near-net-shape output matter. The ceramic shell process fills intricate passages, multi-port valve geometries, butterfly valve profiles, and wall thicknesses down to approximately 2mm for aluminium bronze, with dimensional accuracy and surface consistency that sand casting cannot match.

The near-net-shape output also reduces downstream machining — significant for aluminium bronze, which machines more slowly than steel and requires more tool wear management.

Sand casting is the route for large-section, straightforward-geometry components above the practical range of the investment casting process — large propeller blades, heavy flanges, and thick-section structural parts. The geometry of the component, not the alloy or the production volume, is the primary deciding factor. A complex geometry at any production volume favours lost wax casting; a simple geometry at large section size favours sand casting. Process overview, tolerances, and dimensional capabilities are covered on the investment casting process page.

Applications by Industry

Aluminium bronze investment castings serve a wider range of demanding applications than any other copper casting alloy. The industries served by investment casting span marine and naval, oil and gas, aerospace, chemical processing, water treatment, general manufacturing, and defence — each sector driven by a distinct combination of the alloy's properties.

Marine and Naval — Seawater, Biofouling and Magnetic Permeability

C95800 (AB2) is the dominant grade in marine and naval applications, and understanding why requires understanding what marine service actually demands of a casting. Ship propellers, pump shafts, underwater fastenings, seawater pump impellers, valve bodies, manifolds, and hull fittings operate in an environment that simultaneously demands corrosion resistance, cavitation erosion resistance, biofouling resistance, and — for naval vessels — controlled magnetic signature. No other copper casting alloy delivers all four.

The biofouling resistance of C95800 is particularly significant in long-service applications: the biostatic surface of nickel aluminium bronze deters barnacle and algae attachment, reducing fouling accumulation that increases hull drag and fuel consumption.

For naval and defence applications, C95800 produced to MIL-B-24480 covers submarine valves, sonar equipment housings, mine countermeasure vessel hardware, and periscope components — all specifications requiring magnetic permeability below 1.05 that no ferrous material meets.



Oil and Gas — Offshore Valves, Wellhead Components and Fire Suppression

The oil and gas sector asks aluminium bronze to do several things simultaneously that no other material achieves as a combination: resist corrosive fluids and sour gas (H₂S-containing environments), perform in seawater-exposed offshore conditions, and comply with ATEX non-sparking requirements in explosive-atmosphere zones.

Valve bodies, pump parts, pipe fittings, and wellhead components across offshore installations are cast in C95500 and C95800. Standard C95400 is not adequate for sour service — the nickel addition in C95500 and above provides the dealuminification and corrosion resistance that H₂S-containing environments demand.

Offshore fire suppression systems are a specific application area — manifold valve bodies, nozzle bodies, and breaching adapters (hose coupling adapters that connect suppression lines of different diameters in offshore and industrial installations) are cast in C95800, delivering seawater resistance and non-sparking compliance simultaneously. BOP components requiring yield strengths beyond C95800 capability are specified in C95520 to AMS 4881.

Aerospace — Landing Gear, Actuators and Non-Magnetic Structural Components

C95520 in the AMS 4881 heat-treated condition earns its place in aerospace by solving a problem that neither steel nor standard aluminium alloys can resolve simultaneously: delivering the strength of medium-carbon steel with the corrosion resistance and low magnetic permeability of a copper alloy, in complex geometries that would require extensive machining from bar if produced any other way. Aircraft landing gear bushings and bearings, actuator components, and heavy-duty structural bearings subject to combined cyclic fatigue loading and corrosion are the primary investment casting applications.

For non-magnetic aerospace and defence components — avionics housings, sonar equipment enclosures, and structural components on magnetically sensitive platforms — C95800 investment castings provide the structural integrity of a precision casting with controlled magnetic permeability that steel cannot match.

Chemical Processing — Heat Exchangers and Corrosive Fluid Systems

Chemical processing plants impose conditions that eliminate most copper alloys from consideration: sustained exposure to acids, chlorides, and industrial process chemicals at elevated temperatures, combined with the mechanical demands of pump and valve service. Aluminium bronze's resistance to stress corrosion cracking — a failure mode that removes many other copper alloys from aggressive chemical service — is as important as its general corrosion resistance in this sector.

Heat exchanger tube sheets and bonnets, chemical storage vessel fittings, corrosive fluid pump impellers and housings, and valve bodies handling acid process streams are cast in C95400 for moderate chemical environments and C95500 or C95800 for aggressive chloride-containing or acidic process fluids.

Water Treatment and Desalination

Desalination and water treatment plants impose some of the most demanding operating conditions for pump and valve components — high-pressure seawater or brackish water, continuous cavitation in pump impellers, and chloride concentrations that corrode unprotected ferrous materials within months.

C95800 investment castings for pump impellers, valve bodies, and pipework fittings in seawater desalination service deliver the erosion and cavitation resistance from high-velocity flow that extends component life and reduces plant downtime. For freshwater treatment systems, C95400 provides the required performance at a lower material cost.



General Industrial — Butterfly Valves, Pumps and Process Equipment

C95400 (AB1) covers the majority of general industrial aluminium bronze investment casting demand. Butterfly valve discs, stems and seat rings, centrifugal pump impellers and casings, bearing housings, gear blanks, and worm drive components across chemical processing, food processing, HVAC, and heavy engineering are the core applications.

The combination of wear resistance, strength, and predictable mechanical properties makes C95400 the cost-effective choice for components that do not face the corrosion demands of marine or offshore service. Dimensional capabilities and near-net-shape tolerances achievable for these component geometries are covered on the investment casting dimensions page.



Tooling, ATEX Compliance and Wear-Resistant Components

At the high-hardness end of the aluminium bronze range, C95900 is the grade for forming dies, heavy wear plates, and tooling components where abrasive wear resistance is the primary requirement. C95700 and C95800 cover worm drives, gears, and wear components in magnetic-sensitive environments where non-magnetic properties are required alongside high hardness.

Across the grade range, aluminium bronze's ATEX Zone 1 and Zone 2 compliance — non-sparking under friction in environments containing flammable gases, vapours, or combustible dusts — makes it the material of choice for components in explosive atmosphere environments: non-sparking hand tools, valve components in refineries and petrochemical plants, and equipment in paint manufacturing, grain handling, and mining. In offshore environments, seawater resistance and non-sparking compliance are inseparable requirements — which is why C95800 is specified even where ATEX compliance alone would permit a lower grade.

How to Specify Aluminium Bronze on a Investment Castings Drawing

A correctly specified purchase order for aluminium bronze investment castings is built on five elements, and every one of them matters. The UNS grade number is the foundation — C95200, C95400, C95800, or whichever grade the application requires, not 'aluminium bronze.' The heat treatment condition sits alongside the grade number and is equally important: annealed, TQ50 temper, solution treated, or AMS 4881 heat treated — depending on the grade. Without the heat treatment condition, the foundry is free to supply as-cast material.

The applicable standard — ASTM B148 for US procurement; EN 1982 with the relevant CC designation for European procurement — sets the acceptance criteria. Inspection requirements must be stated explicitly: visual inspection as the mandatory baseline; radiographic testing per ASTM E155 (or EN 12681) for pressure-containing components; dye penetration test per ASTM E165 on all machined surfaces; hydrostatic pressure test for pump bodies, valve bodies, and manifolds.

Finally, EN 10204 Type 3.1 material certification with heat number traceability confirms what was poured and whether the heat treatment was performed to specification.

Pahwa MetalTech's copper alloy investment casting capability covers all nine aluminium bronze grades from C95200 to C95900, including C95520 to AMS 4881, with in-house heat treatment and full material certification.
